*PLC+Touch Screen Automatic Control.
*Compact Design and small size.
*DOW brand RO membrane.
*Factory direct supply, with more than 8years experience.
* Professional Engineering team and manufacturing team.
*Cheap Price.
| YB-SWRO-50TPD | |||
| *Suggested to use flow rate | 2.5M3/H | Recovery rate | 0.38 |
| Applicable power | AC380V, 50HZ, 3Phase | Power | 16.5KW |
| Inlet water TDS | <45000ppm | Freshwater TDS | <600ppm |
| Design pressure | 1000PSI | Working temperature | 5-45℃ |
| Inlet water residual chlorine | <0.1ppm | Working pressure | ≤850PSI |
| Inlet water turbidity | <1 | Inlet water SDI | <5 |
| Equipment specification | 300X250X220(cm) | Equipment net weight | 1000Kg |
| Model/main configuration | YB-SWRO-50TPD |
| Core filtration component | USA DOW 8040 sea water desalination membrane 4 pcs |
| Pretreatment | Sand filter and PP filter |
| Raw water pump | Nanfang brand, 1.5 kw, 380V, 50HZ |
| High-pressure pump | USA import or Italy imported brand stainless steel 316L |
| Instrument | Raw water pump inlet water pressure gauge, high pressure pump, Inlet water pressure gauge, fresh water flow meter |
| Cleaning | dosing system and cleaning system |
