Flow rate: 1.5T/H.
Power: 380V, 50Hz, 3Phase, 19.5KW.
Inlet water TDS <38000PPM.
Outlet water TDS <600PPM.
System Recovery rate: 30%
Function: Treating seawater to drinking water.
Factory Supply, Professional Manufacturer, OEM/ODM service
|
1 |
Pretreatment Part |
|
|
1.1 |
Raw water pump |
|
|
|
Quantity |
1unit |
|
|
Model |
1.5CWX-3 |
|
|
Material |
Iron casting |
|
|
Power |
3.0 kw, 380V, 50HZ |
|
1.2 |
Dosing system |
|
|
1.2.1 |
Dosing tank |
|
|
|
Quantity |
2pcs |
|
|
Volume |
30liter |
|
|
Material |
PE |
|
1.2.2 |
Dosing pump |
|
|
|
Quantity |
3sets |
|
|
Material |
PTFE |
|
|
Flow rate |
0～5L/hr |
|
|
Pressure |
Normal pressure |
|
1.3 |
Sand filter |
|
|
|
Quantity |
1set |
|
|
Type |
Pressure tank |
|
|
Size |
Φ750*1750mm |
|
|
Filter material |
FRP |
|
|
Filtration media |
Quartz sand |
|
|
Including |
Manual operated valves |
|
1.4 |
5μm PP cartridge filter |
|
|
|
Quantity |
1set |
|
|
Flow rate |
5*40in |
|
|
Working pressure |
0.4MPa |
|
|
Material |
UPVC |
|
|
Filtration pore size |
5μm |
|
|
Cartridge material |
PP |
